Refrigeration equipment cold room used for supermarket fish and meat keeping frozen

Refrigeration equipment cold room used for supermarket fish and meat keeping frozen

    • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
    • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
    • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
    • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
    • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
  • Refrigeration equipment cold room used for supermarket fish and meat keeping frozen

    Product Details:

    Place of Origin: Mainland of China
    Brand Name: FAMOUS
    Certification: CE,ISO9001,SASO,SGS,
    Model Number: 960mm & 1180mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD1500 set
    Packaging Details: Standard seaworthy packing
    Delivery Time: within 20-30days
    Payment Terms: 30% T/T IN ADVANCE AND 70% T/T BEFORE SHIPMENT
    Supply Ability: 5000 sets per month
    Contact Now
    Detailed Product Description
    Insulation Material: PU/XPS Panel Thickness: 50, 75, 100, 120, 150 , 200 Mm
    Refrigerating Unit: Bitzer , Copeland Compressor, Evaporator, Condensor Etc. Control System: Temp,humidity,defrosting Auto-controlled
    Cooling Approach: Water Cooled Or Air Cooled Functions: Fresh Keeping ,freezing ,air Conditioning

    Main equipments and materials:
    1. Refrigeration system:
    1.1 Compressor: Copeland,
    1.2 Condensing units: air cooler.
    1.3 Evaporator: air cooler.
    1.4 Coolant: R22 or R404a is available.
    Refrigeration equipment cold room used for supermarket fish and meat keeping frozen
    2. Electric controlling system:
    Schneider electric components, digital display for temperature setting and reading, automatic and manual control, warning light for running failure.

    3. PU Insulation panel, cold store panels:
    3.1 Material: polyurethane (PU), metal sheet.
    3.2 Density of PU: 35~42kg/m3
    3.3 Metal sheet:according to requirements
    3.4 Thickness of panel: 50mm,75mm,100mm,120mm,150mm,200mm

    4. Cold store door, air curtain machine, lighting:
    4.1 Sliding door, manual opening and closing.
    4.2 When door is opened, the air curtain machine and lights in cold storage can be running automatically.









    Room Temp. Storage Product Panel Thickness
    - 5 ~ +20 °C Fruit, Vegetable, Seed 100 mm
    - 10 °C Ice, Ice Cream 100 mm
    - 18 ~ -25 °C Meat, Fish, Chicken, Seafood 150 mm
    -35 ~ -40 °C Meat, Fish, Chicken Seafood Quick Frozen 200 mm



    DOORS

    1).Swing door and Sliding door available.

    2).Swing door: Manual, Automatic available etc.

    3).Door panel made with special pressing technology PU material.

    4).Door frame: color steel or stainless steel.

    5).With Heater and anti-stuck system.



    Hinged doors are of various types such as single leaf or double leaf , overlapping or flush . These doors are

    always open in the outward direction towards either left or the right .

    Refrigeration equipment cold room used for supermarket fish and meat keeping frozen











    Refrigeration equipment cold room used for supermarket fish and meat keeping frozen







    For any quote, please reply the questions below,




    1. What is your cold storage room used for, food, vegetable, meat, ice or others?
    2. What is your required room temperature?
    3. What is the cold storage room dimension, length, width, height?
    4. This projects will build in which country ? Whats the temp in summer over there?
    5. Do you need the refrigerator systems from us, or you will buy from local market?
