Cold Room Panels and CAM Lock Plate Polyurethane Plate Product

Cold Room Panels and CAM Lock Plate Polyurethane Plate Product

    • Cold Room Panels and CAM Lock Plate Polyurethane Plate Product
    • Cold Room Panels and CAM Lock Plate Polyurethane Plate Product
  • Cold Room Panels and CAM Lock Plate Polyurethane Plate Product

    Product Details:

    Place of Origin: China
    Brand Name: FAMOUS
    Certification: CE, ISO
    Model Number: 960mm & 1180mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 square meter
    Price: USD28 -42per square meter depends on your quantity
    Packaging Details: Standard seaworthy packing
    Delivery Time: 15 to 30 working days
    Payment Terms: 30% T/T IN ADVANCE AND 70% T/T BEFORE SHIPMENT
    Supply Ability: 200,000 per month
    Contact Now
    Detailed Product Description
    Product Name: Cold Storage Room Panels Panel Thickness: 50mm -200mm
    Effective Width: 960mm, 1000mm Or Customized Length: Customized, Up To 11.8mts
    Plate Material: Metal,Non-slip Alluminum ,stainless Steel Core Material: Polyurethane Foam,PUR,PIR EPS,XPS
    PU Density: 38-42kgs Color: White ,Grey,Or Customized Color
    Certification: ISO9001, CE Fire Resistant: B1, B2
    Plate Thickness: 0.4mm-0.8mm,according To Your Needs. Cooling System: Our Own Local Brand Or According To Your Needs

                                Cold Room Panels and CAM Lock Plate Polyurethane Plate Product



    Polyurethane foam insulation board / PU sandwich board for cold storage

    1. Light weight, which can reduce construction costs.

    2. Due to the simple installation, it can save time for construction projects.

    3. Both polyester cores of the panel are fireproof and fully comply with relevant standards.

    4. With special coating durability, the warranty period of color coated steel is 10-15 years, the service life of the panel can be as long as 35 years, and the steel plate is sprayed with anti-rust paint every 10 years.

    5. You can choose a wide range of materials: rock wool, polystyrene and polyurethane, etc. These materials have a low thermal coefficient and have excellent thermal insulation properties at high or low temperatures.

    6. Good sound insulation effect, can reach 40-50 decibels.

    7. The edge of the pressed steel plate is clear, and the panel is available in various colors. They meet the requirements of different styles of building materials and are beautiful.

    8. Ideal special designs because they are easy to form and cut.

    Cold Room Panels and CAM Lock Plate Polyurethane Plate Product

    Specification

    Insulation System Specification
    Wall Panel&Roof Panel

    100mm Polyurethane panel;0.426mm painted galvanized steel;

    Paper corner and plastic cover packing

    Floor

    100mm Polyurethane panel;0.426mm painted galvanized steel;

    Paper corner and plastic cover packing

    Half buried Door

    100mm Polyurethane panel;800*1800mm;0.8mm painted galvanized steel;

    Heating wire;Stainless Steel

    Insulation System Accessories

    Sealant;PU foam seal;Water-proof led light;

    Balance window;Steel hanger

    Rear Door Frame

    One single dppr,Rain Shelter and bumper rubber,door holder;

    low temp door seals.

    Cold storage refrigeration system
    Compressor units Bitzer Piston type parallel
    Refrigerator R404
    Evaporator China Brand
    Vavle China Brand
    Control box With voltage protection,pc control
    Temperature

    Vegetable and fruit cold room:2~10℃;Ice cold room:-5~-15℃;

    Fish and meat cold room:-18~-25℃

    Advantage

    (1) Light steel house's structure parts produce as manufacturing factory type and high degree of mechanization, high degree of commercialization .

    (2) Light steel housing construction speed is fast, it is a civilization construction and will not affect the nearby residents

    (3) The steel structure of light gauge steel house is a sustainable development product of environmental protection.

    (4) Light steel house is light weight, seismic performance is good.

    (5) Because of the wall thickness of light steel structure housing is smaller .It can increase the effective use of the area than the brick concrete structure .

    (6) Compared to the light steel structure building with reinforced concrete residential, due to the light steel structure of the steel after recycling, but concrete cannot be recycled. later must be construction waste, causing environmental pressure and concrete need 40 years to completely dry, so easy to cause the indoor humidity, wet, is not conducive to human health. But light steel structure completely without concrete, and therefore does not exist the problem.

    (7) Light steel housing have good anti-seismic performance . Due to the seismic activity is about and activities, so screw nail is tight with light steel structure to composed of a safety box, can't because of the earthquake shaking and collapse of the wall or floor fall endangers the personal safety.

    (8) Light steel building construction using dry construction method, will not cause the waste of water , and save the cost .



    Frequently Asked Questions

    Q1. What is the material of cold storage panel?

    Stainless steel, Painted galvanized steel or Galvanized steel

    Q2. What is the thickness of the cold storage panel?

    The thickness of the cold storage panel is 75mm, 100mm, 150mm, 180mm, and 200mm.

    Q3. What is the applicable temp range base on different thickness?

    1.75mm medium temperature (-5°C or above)

    2.100mm low temperature (-15°C or above)

    3.150mm ultra low temperature (-35°C or above)

    4.200mm ultra low temperature (-50°C or above)

    Q4.If you want to customize the cold storage, the details about the cold storage as follows you should tell me.

    1. What is the size of the cold storage?

    2. What is the cold storage used for?

    3. What is the required temperature of the cold storage?

    Q5.What's the difference of plug-in PU sandwich panel compared with cam-lock PU sandwich panel?

    Plug-in PU sandwich panel is fixed by self tapping screw.(Mainly used in large duty cold storage)

    Cam-lock PU sandwich panel is fixed by cam lock. (Mainly used in small duty cold storage)



    If you have questions, please feel free to contact us email Grace@hfsteelstructure.com.
